Fluvial to torrential phase transition in open canals

1.

Istituto per le Applicazioni del Calcolo "M. Picone", Consiglio Nazionale delle Ricerche, Via dei Taurini 19, 00185 Rome, Italy

2.

Department of Mathematical Sciences, Rutgers University-Camden, 311 N. 5th Street Camden, NJ 08102, USA

Received  April 2018 Revised  August 2018 Published  November 2018

Network flows and specifically water flow in open canals can be modeled bysystems of balance laws defined ongraphs.The shallow water or Saint-Venant system of balance laws is one of the most used modeland present two phases: fluvial or sub-critical and torrential or super-critical.Phase transitions may occur within the same canal but transitions relatedto networks are less investigated.In this paper we provide a complete characterization of possible phase transitionsfor a case study of a simple scenariowith two canals and one junction.However, our analysis allows the study of more complicate networks.Moreover, we provide some numerical simulations to show the theory at work.
